NAV-GEL - Construction Grade Bentonite
NAV-GEL is Bentonite used in civil engineering applications and is traditionally used as a thixotropic, support and lubricant agent in diaphragm walls and foundations, in tunnelling, in horizontal directional drilling (HDD) and pipe jacking.
NAV-GEL Bentonite, due to its viscosity and plasticity, is also used in Portland cement and mortars.
NAV-GEL is high quality sodium activated bentonite clay, designed to meet the requirements of horizontal directional drilling applications and other civil engineering applications which require high rheological properties.
The high Montmorillonite content of NAV-GEL Bentonite Powder gives high swelling value with extreme thermal stability. Due to high Montmorillonite active content it reduces the additions of Bentonite and can maintain Active Clay level.
Applications
- Production of Geosynthetic Clay Liners
- Pilling & Boring
- Horizontal Directional Drilling
- Diaphragm Cut off Wall
- Slurry Coating In Tunnelling
- Pipe Jacking
- Soil Sealing, Sealant, Sanitary Pit Fills
- Drilling Muds
- Cement Slurries
Important Characteristics
- High Swelling Bentonite
- Excellent Plasticity & Viscosity
- High Water Absorption
- Low Filtrate Loss
- Fantastic Gelling Strength
- Enlarged Surface Area
- Low Permeability
- Advance Lubrications
Packing
- 25KG HDPE BAGS
- 50KG HDPE BAGS
- 1 MT JUMBO BAGS
- 1.5MT JUMBO BAGS
- With laminated or with liners customized palletizing
- Valve type bags / PP or HDPE bags / Paper or customized palletizing facility available as per customer requirement like wrapped in Corrugated boxes, jumbo bags, & wooden boxes with SPECIAL packing material support so that bags will not be damage during the transit
